ALLPLAN Civil
Allplan start now - BRIDGE
Modeling of a Prestressed concrete bridge
In this Allplan training you will learn how to create a parametrical 3D bridge model using Allplan Bridge and using Allplan Engineering for further detailing.
Language:
Country settings:
Target groups:
Close
ALLPLAN Civil
Bridge Modeling
Allplan start now - BRIDGE
E-learning
Basic
42min
Course description
The training is designed to guide you through the modeling process for an parametrical 3D Prestressed concrete bridge model using Allplan Bridge and using Allplan Engineering for further detailing of the bridge. The used example is a hollow box concrete girder bridge with three spans. The length of the bridge is 80 meters, and the span lengths are 25, 30 and 25 meters. The bridge has two piers with variable dimensions along the height of 10 meters. The bridge axis is curved in plan and in elevation.
Learning outcomes
- General
- Axis
- Cross-Section
- Structural Members
- Variables and Variations
You can enroll in this course
Login
Language:
Country settings:
Target groups:
ALLPLAN Civil
ALLPLAN Civil for Beginners
A beginner (Level 2) Self-Paced Training for ALLPLAN Civil.
This course covers aspects related to day-to-day work in ALLPLAN Civil. Before taking this course, learners should have a fundamental understanding of both ALLPLAN and ALLPLAN Civil.
Language:
Country settings:
Target groups:
Close
ALLPLAN Civil for Beginners
E-learning
Basic
5h
Course description
This course covers aspects related to day-to-day work in ALLPLAN Civil. Before taking this course, learners should have a fundamental understanding of both ALLPLAN and ALLPLAN Civil.
Learning outcomes
- Import and adjust Axes.
- Modify the Cross Sections used by Structural Members.
- Place Structural Members from Templates.
- Apply expressions and Variations to Structural Members.
You can enroll in this course
Login
